Description
Introductory video about High temperature：
Parameter Information：
| MAGIC-HT-MAX | |||
| Technology | FFF | Max Printing Temperature: | 500℃ |
| Print volume: | W:500mm D:500mm H:700mm W:19.7″ D:19.7″ H:27.6″ | Max hot bed Temp: | 200℃ |
| Filament Diameter: | 1.75mm | Max Chamber Temp: | 150℃ |
| Filament material: | PEEK,PEI,PPSU,PA,PC,ABS,PTEG,ASA,TPU,PLA…… | Wifi control : | Yes |
| Extruder | Individual lifiting dual extruder Liquid cooling | Auto Clean Nozzle : | Yes |
| Nozzle Diameter: | 0.4 mm (standard) 0.2 /0.6/0.8/1.0 mm (Choosable) | Auto leveling : | Yes |
| Nozzle material： | Copper alloy (standard) hardened steel or others (Choosable) | Camera Monitoring : | Yes |
| Layer Thickness: | 0.05-0.3 mm | Support Software : | IEMAI3D, CURA, SIMPLIFY3D |
| Position Resolution : | X/Y:2.5 μm Z :0.78μm | Support File Type : | STL, GCODE,OBJ,3MF … |
| Platform fixed : | Vacuum aspiration | Support System : | Windows 7.8.10.11 64bit |
| Platform material : | Carbon fiber (standard) FEI ,PC | Mahcine size: | 1080*1380*1950 mm |
| Power : | 200-250V ,50~60Hz ,6500W | Package: | 4.79 CBM |
| Power failure recovery : | Yes | N.W. | 750KG |
| No Filament warning | Yes | G.W. | 850KG |
Product Description：
1.High Temperature Printing
With a temperature of 500°C extruder temperature and 200°C hot bed temperature and 150°C chamber temperature, it is able to support most of the plastic on the market .like PEEK/PEKK/PEI/PPSU etc .
2.Individual Lifting Liquid Cooling Dual Extruder
It had a modular mechanism on the extruder which allow it to have simple maintenance and support the corporate print with water soluble material.
3. Auto Leveling
The mesh leveling itself on top of that starts you know ships with the standard 25 points but you can easily change the spacing right there on the machine interface so you do 144 points or virtually as many as you want now.
4.Power Failure Recovery&Filament Absent Warning
If the machine suddenly powers off during the printing process .Turn the power back on ,Follow the prompts to continue printing without losing data.Filament absent also will not losing data.
5.Vacuum Adsorption Platform
Vacuum adsorption is adopted so that there is no limit to the materials that can be used on the platform. You can use FEI, PC material platform.
6.Filament Moisture- Proof Storage
Filament absorb moisture when it is exposed to air. Printing with dry filament improves the mechanical properties and surface quality of 3D printed parts.
Model Show：
Cooperation Case:
Our factory：
Past Awards:
National High Tech Enterprises
From Department of science and technology of China
The award is China’s recognition of technological innovation enterprises.
5 Top Additive Manufacturing Startus in Automotive
From Startus Insight
StartUs Insights is a worldwide operating data science company headquartered in Austria.
Chinese Industrial AM Manufacturer
From 3D natives
3Dnatives is the largest international online media platform on 3D printing and its applications.
Alibaba Gold Honest Enterprise Certification
From Alibaba
Alibaba inspected the factory and recognized our strength as a manufacturer.
Bronze Award Of Industry Outstanding Brand
From 3D printing Innovation Center
Founded in 2013, the center has developed into the most influential 3D printing platform in China
Global 2019 Best PEEK 3D Printer
From Aniwaa
Aniwaa is an independent online platform facilitating the discovery.
Service Support:
1.When you get the printer, check the packing if any broken,then unpack it; then connect power,check XYZ transportation,do bed calibration; then print the test file which is in SD card. If ok, then you can print. No need other special operation.
2.If you have any question about printing, you can send email to me also, then i will ask engineer to reply. It’s better to contact us at Wechat, because we can make a group with engineers. Or use Whatsapp is also quick .
Additional information
| Environmental friendly | Environmental friendly, Strong toughness |
|---|
